0.5MM FFC FPC Connector On Horizontal Latch To Connect PA9T Material
Product attributes:
| Type | FPC/FFC connector horizontal |
| PIN number | 4-40 |
| Spacing | 0.5mm |
| Product height | 2.0mm |
| Rated current | 0.5A AC (RMS) |
| Rated voltage | 50V AC (RMS) /DC |
| Contact resistance | 20 m Omega Max |
| Insulation resistance | 500 M Omega Min |
| Voltage resistance | 200V AC r.m.s |
Product introduction:
FPC FFC is an indispensable part of electronic equipment. Following the current flow path, you will always find one or more FPC FFC flat connectors. The form and structure of FPC FFC flat connector are varied. With different application objects, frequency, power, application environment and so on, there are various forms of FPC FFC flat connectors.
The basic common sense of the FPC connector:
Use common sense:
The general FPC connector has many pins, so the connector must be correctly aligned to the interface of each pin hole to plug in. Otherwise, if the position of the pin socket of the connector is not completely aligned, it is easy to bend or break the pin of the connector.
Use common sense two:
On the use of FPC connector, please do not touch the pin pin of its interface casually, so as to avoid some electric shock and other accidents. Because the connector will have electric current at every end of the interface when the connector is in the power supply, if it touches it, it will lead to the situation of electric shock. And because the connector pin is usually relatively small and sharp, if you touch it with your hands, it will easily cause some scratches.
Why Choose CNJWY:
1. Concentrating and concentrating "is a consistently adhered service concept
2. The company has a standardized, standardized and professional service system to provide customers with rich service experience and professional knowledge to ensure that customers enjoy high quality, high efficiency and personalized service resources.
3. Meet the needs of different levels of customers to achieve the value of customers in the use of products.
4. It is our duty to serve you. Your satisfaction is our pursuit.
5. After sale service four "to": customer oriented, in good faith as the principle, with the most economic means, with the fastest speed.
The FFC FPC specifications can be divided into the following:
The 0.5MM 1.0MM 1.25MM 0.3MM is connected to the bottom, horizontal vertical, and lock type products can be referred to the following combination drawings.
Product Tags:
|
|
Electronic FPC Cable Connector 0.5mm Horizontal PA9T Material Folding Resistance Images
|
